Trisio Lite2

If you have just received your camera, please watch this video for a quick start.

Instruction
  • 01

    Wi-Fi Connection

    1. Please make sure that the camera is switched on and that the indicator light is blue and always on.
    2. Search the Wi-Fi list on your phone, select “trisio__******” and connect.
    3. Enter the default password:12345678.
    4. Make sure that the location service of your phone is turned on. When connecting to the Trisio camera Wi-Fi, you will be prompted that there is no internet connection, please choose to continue connecting.

  • 02

    Initialization Process

    1. An initialization process for the first time to connect is a prerequisite. Tap Start to initialize.
    2. Keep logged in, and initialization will be completed in seconds.
    3. With initialization complete, tap OK to confirm.

  • 03

    Image Shooting

    1. Enter shooting interface, create a folder at photo albums
    2. Tap in a name for the folder, type Unnamed for the panaroma
    3. Custom names, after all setup, tap OK
    4. Back to the shooting interface and tap the red shooting icon
    5. Metering, users can see a preview when shooting
    6. A prompt tone will be made when shooting is completed and automatical stitching will start immediately
    7. After stitching, tap to enter the album
    8. Select the panaroma and slide to observe the shooting effect
    9. Tap the upper icon to download the panorama to the phone album

  • 04

    Setup

    1. Tap Setting icon to enter setting interface.
    2. Tap Set Nadir Logo to set a logo at the bottom.
    3. Tap “+” to select a nadir from the album.
    4. Select the save nadir from the local album.
    5. Confirm to change nadir after select.
    6. Nadir in the panorama can be changed.

  • 05

    Batch Stitching

    1. Enter the album interface and tap Batch Stitching
    2. Select the panoramas in batch and tap Stitching
    3. Once stitching starts, please do not turn off the phone or camera
    4. After stitching completes, tap OK
    5. The stitched panorama will be saved at the album
